In-Vehicle Data Acquisition System (IVDAQS)

April 10, 2012 By: admin Category: Automotive, Data Acquisition, Microcontroller, Project, Renesas Comments Off on In-Vehicle Data Acquisition System (IVDAQS)

Data Acquisition System for Bike

This In-Vehicle Data Acquisition System (IVDAQS) can be used to monitor the performance of vehicle which includes engine temp, battery voltage monitoring, engine RPM, speed acceleration, braking rate, engine run time and lots more. The system is built based on M16C/62P microcontroller.

PIC Based EPROM Reader

September 26, 2011 By: admin Category: Data Acquisition, Miscellaneous, PIC, Project, USB No Comments →

EPROM and Flash Reader

This project allows you to read many common EPROM and Flash memory chips. It’s equipped with USB interface that uses FTDI USB to serial chip. The PIC18F4550 microcontroller firmware handles the various differences of the range of EPROM chips. The project only uses HyperTerminal PC software to control and read the chips. Intel hex and […]


Low-Cost AVR Based Logic Analyzer

July 05, 2010 By: admin Category: AVR, Interfacing, Microcontroller, Monitoring, Project, Tools No Comments →

Low-Cost-Logic-Analyzer-image

This Logic Analyzer project allow you to monitors and captures a number of digital signals. It uses PC to display the data processing. The system consists of ATmega88-20PU AVR microcontroller as main processor and some simple components used for the interfacing with the PC, the man and the probes.

Telemetry Device, ATmega8

February 24, 2010 By: admin Category: AVR, Data Acquisition, Miscellaneous, Monitoring, Project No Comments →

AVR-Project-Telemetry-Device

The Low Cost Telemetry Device (LTD) provides a low cost, minimal parts count Telemetry keyer using an Atmel’s ATMega8 Microcontroller. The LTD sends data by measuring voltage levels of up to four analog channels via its on-chip 10-bit Analog to Digital Converter (ADC) and converting them to numbers and sending the measurements via Morse Code. […]
